Marine Grease Trap
As per Marpol 73/78 Annex IV and V 5.4.4 Galley wastes
All galley wastes that may contain grease should flow through grease traps to a retaining box prior to discharge overboard with a distance of 3 N.M. from the closets line of land (territorial sea – 12 N.M.) or to a treatment aboard ship.
The grease collected may be disposed of by incineration, by storage for shore disposal, or in any manner stated by the law.
Food waste needs to be handled as well as per Annex V
DeFraWater® is a partner with Grease Guardian® for the distribution of their grease separation equipment for galleys and plant rooms on board any vessels.
The proposed Marine Range has different design configurations to suit confined spaces, and together with unique features including automated waste oil recovery, will operate efficiently in marine environments.
Proven results give us confidence to promote the Grease Guardian Marine Range from super yachts to cruise liners and everything in between.
Suitable grease removal system will be required to pre-treat the kitchen waste water accordingly, prior to discharge at sea or to go for treatment on board.
In order to keep the best working condition of the on board waste water treatment plant that receives kitchen waste water, it is good practice to reduce the loading of the kitchen waste water. This is done by reducing/removing solids and fat oil and grease before the water will enter the plant.
Grease Guardian product portfolio offers a wide range selection of Grease Trap such as
- At Source manual Grease Trap allowing only cleaner water through
- Centralised manual Grease Traps allowing only cleaner water through
- At Source Grase Trap with auto-skim and automatic solids transfer option
- Centralised Grease Trap with auto-skim and automatic solids transfer option.
with customised options according the specific requirements such as higher flows, naval applications, monitoring, shock mounted equipment and other requirements contact the supplier for details.
Under Sink Model:
D1R M, D2R M
- Automatic grease trap and grease removal units with 0.75 l/s & 1.25 l/s Flow Rate
- Specific designed for under sink installation and at source solution.
- Removable solids basket of 3 lts and 4 lts volume capacity
- Traps food waste and grease and removes grease with programmable skimming cycles.
- Shut off valves for high sea operation, manual washing system as standard.
- Material, Exterior 16 gauge 316 stainless steel bright finish.
- Suitable for Yacht and Superyacht with meal preparation from 20 to 100 x day
- Easy to install and maintain in confined spaces.
Centralised Model:
D3R M, GGX 50 M, GGX 75 M
- Automatic grease trap and grease removal units with 1.75 l/s , 3 l/s and 4.5 l/s Flow rate, ideal for centralised installations.
- Removable solids basket or Automatic solids transfer.
- Solid Basket capacity 8 lts & 9.5 lts volume on manual model.
- Automatic solid transfer by pump.
- Traps food waste and grease and removes grease with programmable skimming cycles.
- Shut off valves for high sea operation, automatic washing system as standard.
- Material, Exterior 16/14 gauge 316 stainless steel bright finish.
- Suitable for Superyacht and Commercial Vessel with meal preparation from 100 to 350 x day
- Easy to install and maintain in confined spaces, with BMS volt free contacts.
- Customised skid can be provided according to customer needs.
TRAPS AND REMOVES FATS, OILS & GREASE ON MARINE VESSELS
Stainless steel fabrication in SS316
Traps and removes fats, oil & grease on vessels
Intelligent design with solid retention/automatic solid transfer Automatically removes 98% of grease and food waste
Self cleaning facility
Product ranges from 0.75L to 20L per second
Easy to install and maintain, BMS remote monitoring connection Full customer support
